Device Interfaces
• 5 x Gigabit Ethernet LAN ports, 1 x power connector
Standards
• IEEE 802.3 10BASE-T Ethernet
• IEEE 802.3u 100BASE-TX Fast Ethernet
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x Flow Control
• IEEE 802.3az Energy-Efficient Ethernet (EEE)
Functionality
Advanced Features
• Green Ethernet
• 10 Gbps switching fabric
• Auto MDI/MDIX crossover for all ports
• Secure store-and-forward switching scheme
• Full/half-duplex for Ethernet/Fast Ethernet speeds • IEEE 802.3x Flow Control
• Supports 9KB Jumbo Frame
• Supports IEEE 802.1p QoS
Data Transfer Rates
Ethernet:
• 10 Mbps (half duplex)
• 20 Mbps (full duplex) Fast Ethernet:
• 100 Mbps (half duplex)
• 200 Mbps (full duplex)
Gigabit Ethernet:
• 2000 Mbps (full duplex)
Transmission Method
• Store-and-forward
MAC Address Table
• 2 K
MAC Address Learning
• Automatic Update
Packet Filtering/Forwarding Rates
• Ethernet: 14,880 pps per port
• Fast Ethernet: 148,800 pps per port
• Gigabit Ethernet: 1,488,000 pps per port
Packet Buffer
• 128 KB
Garantia 24 meses
