| Entrada de vídeo IP | 16-Channel |
| Ancho de banda entrante | 80 Mbps |
| Ancho de banda saliente | 60 Mbps |
| Resolución de salida HDMI | 1 Channel, Resolution: 3840×2160/30Hz, 1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| Resolución de salida VGA | 1 Channel, Resolution: 1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| Modo de salida de video | HDMI/VGA Simultaneous Output |
| Pantalla multivista | 1/4/6/8/9/16 |
| DESCODIFICACIÓN |
| Compresión de Audio | G.711A/G.711U/G.726 |
| Compresión de Video | H.265+/H.265/ H.264+/H.264 |
| Resolución de registro | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ |
| | 2CIF/CIF/QCIF |
| Reproducción sincrónica | 16-Channel |
| Capacidad | 25fps: |
| | 2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP |
| | 30fps: |
| | 4-ch @ 3MP, 2-ch @ 5MP |
| Administración de Grabación |
| Modo de grabación | Manual Recording, Scheduling Recording, Motion Detection Recording |
| Modo Playback | Instant Playback, Regular Playback, Tag Playback, Event Playback |
| Modo de Respaldo | Regular Backup, Video Clip Backup |
| Función Playback | Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full |
| | Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off |
| RED |
| Protocolo | UPnP (Plug and Play), NTP (Network Timing) |
| Mobile Phone Access | Android, iOS |
| Web Browser | Chrome (57+), Firefox (52+), Edge (91+) |
| Interoperability | ONVIF, CGI |
| External Interface |
| Network Interface | 1, RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface |
| USB Interface | 1 Front USB 2.0 Port, 1 Rear USB 2.0 Port |
| Audio Interface | 1, Audio In; 1, Audio Out |
| Alarm In/Out | N/A |
| Serial Interface | N/A |
| Power | 1× DC Jack |
| Reset Button | 1 |
| Speaker | N/A |
| eSATA | 1 |
| HDMI | 1 |
| VGA | 1 |
| DISCO DURO |
| SATA | 2 SATA Interfaces |
| Capacidad | Up to 10 TB Capacity for Each HDD |
| PoE |
| Standard | 802.3at/af Compliant |
| Interface | 1- 16, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| PoE Budget | 90 W Available for All PoE+ Ports, 30 W Max per Port |
| Alarm |
| General Alarm | Motion Detection, Video Tampering, Line-Crossing Detection, Intrusion Detection, |
| | Region Entering Detection, Region Exiting Detection, Object Abandoned/Removal Detection, Vehicle Detection, Human Detection, Smart Frame |
| Anomaly Alarm | Video Loss, Offline and IP Conflict, Disk Exception, Login Exception, Fan Exception |
| Alarm Linkage | Recording, White Light Alarm, Buzzer, Log, Audible Alarm |
| GENERAL |
| Storage Temperature | -40–70 °C |
| Storage Humidity | 10%~90% RH Non-Condensing |
| Contenido del Paquete | VIGI Network Video Recorder |
| | Power Adapter |
| | Power Cables |
| | HDD Power Cables |
| | HDD Data Cables |
| | Mounting Accessories |
| | Mouse |
| | Quick Installation Guide |
| Working Temperature | NVR: -10–55 °C |
| | Power Adapter: 0–40 °C |
| Working Humidity | 10%~90% RH Non-Condensing |
| Dimensiones (An x Pr x Al) | 330 × 285 × 45 mm |
| Peso neto | 1.9 Kg |
| Peso bruto | 3.2 Kg |
| Power Supply | 53.5V DC/2.43A |
| Consumo de energía | 6.2 W (Without Disk) |
| | 40 W (With Disk) |
| Certificaciones | CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI |
