Descripción
| LA SERIE | Serie S |
| MODELO | S100 TG |
| TIPO DE CAJA | Micro Case |
| DIMENSIONES (AL X AN X PR) | 441 x 220 x 411 mm |
| (17.36 x 8.66 x 16.18 inch) | |
| PESO NETO | 6.1 kg / 13.45 lbs. |
| PANEL LATERAL | Tempered Glass x 1 |
| COLOR | Exterior & Interior : Black |
| MATERIAL | SPCC |
| SISTEMA DE REFRIGERACIÓN | Rear (exhaust) : 120 x 120 x 25 mm fan (1000rpm, 16 dBA) |
| BAHÍAS DE EXPANSIÓN | 2 x 2.5” (HDD Bracket); 2 x 3.5“ or 2 x 2.5” (HDD Rack); |
| RANURAS DE EXPANSIÓN | 4 |
| PLACAS BASE | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), |
| PUERTOS E/S | 1 x USB 3.0, 2 x USB 2.0, 1 x HD Audio, |
| FUENTE DE ALIMENTACIÓN | Standard PS2 PSU (optional) |
| COMPATIBILIDAD VENTILADORES | Front: 3 x 120mm, 2 x 140mm |
| Top: 2 x 120mm, 2 x 140mm, 1 x 200mm | |
| Rear: 1 x 120mm, | |
| COMPATIBILIDAD RADIADORES | Front: 1x 240mm, 1 x 280mm |
| Top: 1 x 240mm, 1x 280mm | |
| Rear: 1 x 120mm, | |
| LIMITACIONES | CPU cooler height limitation: 165mm |
| PSU length limitation: 160mm | |
| VGA length limitation: 330mm |
